How Gcore CDN + WAAP process traffic

Gcore WAAP flow overview

A practical mental model of the request flow and response flow when a client hits an application protected by Gcore CDN and Gcore WAAP. Hover the diagram steps for details.

Diagram: request path → origin, then response path → back to the client. Tip: hover nodes for tooltips.
Request flow (Client → Edge → WAAP → Load Balancer → Origin server) Response flow (Origin server → WAAP → Edge → Client) Client CDN Edge ACL > CDN Rules > Rewrites WAAP L7 DDoS > Rules > Policies Allow > Block > Captcha > JS Load Balancer (Optional) Origin server Origin server WAAP Response rules • Challenges Block / Captcha / JS pages CDN Edge Client
Note: The exact feature names and ordering can depend on your product setup, but the diagram reflects the practical “how it feels” flow when troubleshooting.

Gcore Request Flow

  • CDN Edge: client TLS/HTTP terminates at the edge
  • Edge controls: ACL, CDN rules, rewrites
  • WAAP:
    • L7 DDoS protections (rate limiting, JavaScript DDoS gateway)
    • Rule engine (global policies + custom/advanced rules)
    • Priority: Allow > Block > Captcha > Handshake (JS validation)
  • Load Balancer: forwards allowed traffic to upstream(s)
  • Origin server: your origin app / API receives the request

Gcore Response Flow

  • Origin server: returns a response (200/4xx/5xx)
  • WAAP:
    • Response rule engine (e.g., response inspection, sensitive data exposure)
    • WAAP response pages (block/captcha/challenge) when a request is convicted
  • CDN Edge: applies caching rules (unless disabled for APIs)
  • Client: receives upstream response or WAAP challenge page

Try it live (your demo endpoints)

These are the endpoints you already use in your demo JS (/api/*), plus your existing tools pages. They’re perfect for testing WAAP actions like rate limiting, bot/JS challenge, allow/block rules, and header inspection.

API calls

Tools pages

Practical WAAP test ideas

  • Enable a rate limit on /api/ratelimit and run burst traffic from the homepage demo.
  • Create a block rule on suspicious User-Agent and validate challenge pages.
  • Test allow rules by IP (your office/VPN) vs. block for others.
  • Test header-based rules (e.g., missing Authorization → block).
  • Ensure API endpoints return Cache-Control: no-store to prevent CDN caching.
The goal of this page is to quickly understand where to look when something is blocked, challenged, cached, or rewritten.
